规格:

MODEL	SPS/B(A)-B1202-01	SPS/B(A)-B1202-02	SPS/B(A)-B1202-03
APPLICATION	For Size Button	For large Size Button	For Small&Large Size Button
WIPER TYPE	Mechanical	Mechanical	Solenoid
BUTTON SIZE	(Φ8-Φ20)	(Φ8-Φ32)	(Φ8-Φ32)
SEWING AREA	X:6.5mm,Y:6.5mm
SEWING SPEED	Max.2,500spm(Standard:2,200spm)
NEEDLE	DP×17#4
HOOK	Standard Shuttle Hook
HEIGHT OF BUTTON CLAMP	Max.13mm
HEIGHT OF PRESSER FOOT	Provided
MEMORY	EP-ROM
NO.OF PATTERNS	Max.99Patterns(Standard 33 Patterns)
NO.OF STITCHES	Max.10,000Stitches
ENLARGING/REDUCING	20~200%
MOTOR	SPS/B-Series:550W AC Servo Motor
	SPS/A-Series:550W AC Servo Motor
FEEDING SYSTEM	Feeding by Stepping Motor
POWER	1-Phrase 100V-240V,3-Phrase 200V-440V,50-60Hz
