规格:

MODEL	SPS/B(A)-1306H□	SPS/B(A)-1306G□
APPLICATION	Heavy Materials	General Materials
SEWING AREA	130×60mm
SEWING SPEED	Max.2,500spm(Stitch Length 3mm or less)
STITCH LENGTH	0.1~12.7mm
NEEDLE	DP×17#18	DP×5#14
HOOK	Large Shuttle Hook
HEIGHT OF PRESSER PLATE	Max.25mm(Penumatic Spectification:Max.30mm)
HEIGHT OF PRESSER FOOT	Max.20mm
PRESSER STROKE	4mm(0~7mm)
TRIMMING DEVICE	Provided
WIPER	Provided(Electronic Wiper)
EMERGENCY SWITCH	Provided
MEMORY	3.5"FDD(2HD)
NO.OF PATTERNS	Max.691 Patterns
NO.OF STITCHES	Max.360,000Stitches
ENLARGING/REDUCING	20~200%(1% step)
MOTOR	SPS/B Series:500W Direct AC Servo Motor
	SPS/A Series:550W AC Servo Motor
FEEDING SYSTEM	Feeding By Stepping Pulse Motor
POWER	1-Phrase 100V~240V,3-Phase 200V~440V,50~60Hz
PNEUMATIC	0.49MPa(5Kgf/cm2)
